Harfington Uxcell 1/4" PT DC24V Brass Normally Closed Direct Acting Electric Solenoid Valve

Uxcell 1/4" PT DC24V Brass Normally Closed Direct Acting Electric Solenoid Valve

ID:
AU$25.30 Regular price
AU/
About this item
  • In stock, ready to ship
Cart
Cart
About this item
Specification

Specification

Inquiry submitted successfully
We will reply within 24 hours during work time. If you haven't received the reply by then, please check your spam. Thank you!
Payments will be processed via the website or Stripe payment link. Please note that domain contact emails other than @harfington.com should not be trusted.
Product Description:

Specification:

Model Number:2W-025-08B

Net weight:305g

Body material:Brass

Oil seal material:NBR

Type : Normally closed

Flow aperture:2.5mm

Thread size:1/4PT

Voltage:DC24V

Wire Long : 250mm /9.84"

Operating voltage range : 10%

Mode of action : Direct motion

Working medium : air, water, oil

Working temperature : -10~100 degrees Celsius

Use pressure : 0~1Mpa

Total Size :75x42.5x42.5mm / 2.95x1.67x1.67 inch (LxWxH)

Normally closed type: power on, always off when not energized

Wiring method: two wires are connected

Installation method: the bottom indicates the direction of water flow, which in turn will affect the use.



Package Included:

1 x Solenoid Valve



Description:

1.The use of a direct-acting diaphragm structure without pressure starts expands its field of use

2.The flat diaphragm structure is reliable in opening and closing, and the service life of the product is enhanced

3.The valve is N / C (normally closed), meaning it will shut down when not powered

4.The valve body made of brass has excellent anti-pressure explosion-proof and corrosion resistance, fast heat dissipation, stable operation and no noise

5.Copper core coil component is sufficient, work response is fast, not easy to heat

6.When installing the solenoid valve, the solenoid valve mark on the valve body should be consistent with the flow of the pipeline fluid

7.This brass solenoid valve has a wide range of applications and is easy to replace broken valves for water, air.



Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
AU$25.30 Regular price
AU/
  • In stock, ready to ship
Cart
Cart
Free Shipping over $20 Free upgraded to DHL over AU$300
By default, UPS or DHL or equivalent express delivery options will be selected, with an estimated delivery time of 4-7 days. Except for remote areas or extremely large volume products.

Product Variants

Products Title ID Price Qty
Products Title ID Price Qty
Qty: {[total.qty]} Item(s)
Total Price: {[handleCurrency(total.price*100)]}
View more

Description

Description

Specification:

Model Number:2W-025-08B

Net weight:305g

Body material:Brass

Oil seal material:NBR

Type : Normally closed

Flow aperture:2.5mm

Thread size:1/4PT

Voltage:DC24V

Wire Long : 250mm /9.84"

Operating voltage range : 10%

Mode of action : Direct motion

Working medium : air, water, oil

Working temperature : -10~100 degrees Celsius

Use pressure : 0~1Mpa

Total Size :75x42.5x42.5mm / 2.95x1.67x1.67 inch (LxWxH)

Normally closed type: power on, always off when not energized

Wiring method: two wires are connected

Installation method: the bottom indicates the direction of water flow, which in turn will affect the use.



Package Included:

1 x Solenoid Valve



Description:

1.The use of a direct-acting diaphragm structure without pressure starts expands its field of use

2.The flat diaphragm structure is reliable in opening and closing, and the service life of the product is enhanced

3.The valve is N / C (normally closed), meaning it will shut down when not powered

4.The valve body made of brass has excellent anti-pressure explosion-proof and corrosion resistance, fast heat dissipation, stable operation and no noise

5.Copper core coil component is sufficient, work response is fast, not easy to heat

6.When installing the solenoid valve, the solenoid valve mark on the valve body should be consistent with the flow of the pipeline fluid

7.This brass solenoid valve has a wide range of applications and is easy to replace broken valves for water, air.



Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
